This equipment is widely applicable to brushed motor production lines, with primary applications in electric motors, automotive pumps, home appliances, and industrial motor manufacturing.
NLRT-01A Rotor Multi-process Pressing Machine
NLRT-05B Fully Automatic Rotor Paper Inserting Machine
NLRT-01B Rotor Dual-Flyer High-Speed Winding Machine
NLRT-09B Rotor Intelligent Spot Welding & Testing All-in-One Machine
NLRT-06B Fully Automatic Rotor Laminating Machine
NLRT-15A Rotor Fully Automatic Precision Turning Machine
NLRT-CP01 Rotor Finished Product Testing Machine
NLRT-4000 Rotor Finished Product Unloading Machine
| Input Voltage | AC 220V ±10%, 50Hz；AC 380V ±10%, 50Hz |
| Air Supply Pressure | 0.4-0.7 MPa |
| Overall Dimensions | Customized per customer requirements |
| Product Range | Ф20–Ф85 mm, Stack Height: 20–65mm (Customizable) |
| Wire Diameter Range | Ф0.2–Ф1.2 mm |
| Feeding Method | Automatic Loading/Unloading |
