RM16LTBX-12V DC Motor Application Scenarios
1.Vehicle Power Unit Drive
Core power component for 12V vehicle hydraulic power units, delivering 6N·m high torque for commercial vehicles, vans and truck auxiliary systems.
2.Industrial Lifts & Scissor Lift Actuation
Ideal for powering heavy-duty scissor lifts, table lifts and vertical lifting equipment, optimized for 2min-9%ED intermittent operation in industrial environments.
3.Boarding Trucks & Access Lift Systems
Perfect for integrating into boarding trucks, wheelchair lifts and step ramps, ensuring stable, smooth lifting for heavy-load access operations.
4.Specialized Industrial & Off-Highway Equipment
Suitable for driving specialized industrial machinery, automation equipment and material handling systems requiring 12V DC high-power drive.
5.Vehicle Modification & Aftermarket Retrofit
Supports optional 24V/48V configurations, ideal for custom modification of special vehicles, electric vehicles and non-standard industrial equipment.
6.OEM Integration for Vehicle & Machinery Manufacturers
With customizable voltage, power and structural parameters, tailored for vehicle manufacturers, equipment integrators and industrial automation projects, supporting mass OEM orders.
RM16LTBX-12V DC Motor Technical Specifications
| Parameter | Specification |
| Motor Model | RM16LTBX-12V |
| Scope of Application | Vehicle Power Units, Lifts, Boarding Trucks, Specialised Equipment |
| Rated Voltage | 12V DC (Optional: 24V, 48V) |
| Rated Power | 1600W |
| Rated Current | 190A |
| Rated Torque | 6 N·m |
| Working System (Duty Cycle) | 2min-9%ED |
| Insulation Grade | Class F |
| Protection (Waterproof) Grade | IP54 |
| Tooth Number | 9 |
| Rotation Direction | CW (Clockwise) |
| Optional Configuration | 24V, 48V |
