RM2412FCE DC Motor Application Scenarios
1.Vehicle Power Unit Drive
Core power component for vehicle-mounted hydraulic power units, delivering reliable 2.4N·m torque for auxiliary systems in commercial vehicles, vans and trucks.
2.Lift & Scissor Lift Actuation
Ideal for powering small lifts, scissor lifts, table lifts and mechanical lifting equipment, optimized for intermittent operation (1.5min-7%ED) in industrial and automotive applications.
3.Boarding Truck & Access Lift Systems
Perfect for integrating into boarding trucks, wheelchair lifts, step lifts and vehicle access ramps, ensuring smooth and stable lifting operations.
4.Specialized Industrial Equipment
Suitable for driving specialized industrial machinery, automation equipment, mechanical actuators and custom material handling systems requiring 24V DC power.
5.Vehicle Modification & Aftermarket Retrofit
Supports optional 12V/48V/60V/72V configurations, ideal for custom modification of special vehicles, electric vehicles and non-standard equipment.
6.OEM Integration for Vehicle & Machinery Manufacturers
With customizable voltage, power and structural parameters, tailored for vehicle manufacturers, equipment integrators and industrial automation projects, supporting mass OEM orders.
RM2412FCE DC Motor Technical Specifications
| Parameter | Specification |
| Motor Model | RM2412FCE |
| Scope of Application | Vehicle Power Units, Lifts, Boarding Trucks, Specialised Equipment |
| Rated Voltage | 24V DC (Optional: 12V, 48V, 60V, 72V) |
| Rated Power | 1200W |
| Rated Current | 56A |
| Rated Torque | 2.4 N·m |
| Working System (Duty Cycle) | 1.5min-7%ED |
| Insulation Grade | Class F |
| Protection Grade | IP43 |
| Tooth Number | 2 |
| Rotation Direction | CW (Clockwise) |
| Optional Configuration | 12V, 48V, 60V, 72V |
